Miller Continuum™ Swingarc™, 12 Ft
$16,994.00
Description
[vc_row][vc_column][vc_tta_tour active_section=”1″][vc_tta_section title=”Features and Benefits” tab_id=”1604679956767-f4ddfaaa-ce9e940f-11e16ab7-90d9262f-f77d”][vc_row_inner][vc_column_inner][vc_column_text]
All-new power source design
- Smart and powerful digital design has the fast response needed to deliver the most stable welding performance for better welding results.
- Developed as a platform to meet current and future needs with integrated expansion capabilities.
[/vc_column_text][/vc_column_inner][/vc_row_inner][vc_separator css=”.vc_custom_1604941865849”][vc_row_inner][vc_column_inner width=”1/3″][vc_single_image image=”5777″ img_size=”full” alignment=”center”][/vc_column_inner][vc_column_inner width=”2/3″][vc_column_text]
Superior Arc Performance
- Improved Accu-Pulse® provides less spatter, better arc control and less heat input – very forgiving to changes in stick-out.
- Improved MIG performance delivers consistently smooth arc starts and reduced spatter.
- Improved RMD – designed for thin materials and gap filling with very low spatter.
[/vc_column_text][/vc_column_inner][/vc_row_inner][vc_separator css=”.vc_custom_1604941865849”][vc_row_inner][vc_column_inner][vc_column_text]
New Weld Processes
- Versa-Pulse™ is a fast, low-heat, low-spatter process resulting in faster travel speeds and increased productivity for semi-automated and automated welding. Typically used on thin materials up to 1/4 inch., great for gap filling on sheet metal and tube applications.
- High-Deposition MIG offers higher deposition rates than standard spray transfer — resulting in faster welding and increased productivity. Typically used for thicker material and larger welds (6 to 8 mm).
[/vc_column_text][/vc_column_inner][/vc_row_inner][vc_separator css=”.vc_custom_1604941865849”][vc_row_inner][vc_column_inner width=”1/3″][vc_single_image image=”5775″ img_size=”full” alignment=”center”][/vc_column_inner][vc_column_inner width=”2/3″][vc_column_text]
Adaptable to a Variety of Weld Cell Configurations
- Flexible user interface location (power source, feeder, remote operator interface)
- Welding Intelligence™ Solutions: Insight Core™ (standard) and Insight Centerpoint™ (optional)
- Easily add process and programs
- Wire feeder is easily configurable for standard spool sizes, 60-pound spools or bulk-feeding systems
[/vc_column_text][/vc_column_inner][/vc_row_inner][vc_separator css=”.vc_custom_1604941865849”][vc_row_inner][vc_column_inner][vc_column_text]
Auto-Line™ Power Management Technology
- Allows for any input voltage hookup (230–575 V) with no manual linking. Eliminates weld defects caused by dirty or unreliable power.
[/vc_column_text][/vc_column_inner][/vc_row_inner][vc_separator css=”.vc_custom_1604941865849”][vc_row_inner][vc_column_inner width=”1/3″][vc_single_image image=”5772″ img_size=”full” alignment=”center”][/vc_column_inner][vc_column_inner width=”2/3″][vc_column_text]
All-new feeder design
- Faster motor response provides the best arc starts with the least amount of spatter.
- Tru-Feed ™ Technology provides precise feeding operation for stable arc performance.
[/vc_column_text][/vc_column_inner][/vc_row_inner][vc_separator css=”.vc_custom_1604941865849”][vc_row_inner][vc_column_inner width=”1/3″][vc_single_image image=”5776″ img_size=”full” alignment=”center”][/vc_column_inner][vc_column_inner width=”2/3″][vc_column_text]
LCD Display
- New user interface makes the system easy to set up and adjust with minimal training. Shows complete words, graphics and numeric values.
[/vc_column_text][/vc_column_inner][/vc_row_inner][vc_separator css=”.vc_custom_1604941865849”][vc_row_inner][vc_column_inner width=”1/3″][vc_single_image image=”5774″ img_size=”full” alignment=”center”][/vc_column_inner][vc_column_inner width=”2/3″][vc_column_text]
Easy to Set Up and Adjust with Minimal Training
- 8 program/memory buttons
- USB functionality for updates, cloning and more.
- Browser-based connection to remotely view and adjust machine parameters, configure machine settings and ability to set locks and limits.
[/vc_column_text][/vc_column_inner][/vc_row_inner][vc_separator css=”.vc_custom_1604941865849”][vc_row_inner][vc_column_inner width=”1/3″][vc_single_image image=”5778″ img_size=”full” alignment=”center”][/vc_column_inner][vc_column_inner width=”2/3″][vc_column_text]
Tool-less, Lockable Rotatable Drive
- Allows operator to rotate the drive, eliminating severe bends in the wire feeding path.
- Extends gun-liner life.
- Aids in feeding difficult wires.
[/vc_column_text][/vc_column_inner][/vc_row_inner][vc_separator css=”.vc_custom_1604941865849”][vc_row_inner][vc_column_inner width=”1/3″][vc_single_image image=”5773″ img_size=”full” alignment=”center”][/vc_column_inner][vc_column_inner width=”2/3″][vc_column_text]
Balanced-pressure Drive-roll Design and Tensioner
- Feed wire in its truest and straightest form for consistent feedability, resulting in better welding performance.
[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_tta_section][vc_tta_section title=”Documents” tab_id=”1604679956790-193a91fd-6cd9940f-11e16ab7-90d9262f-f77d”][vc_column_text]Spec Sheet (ENG)[/vc_column_text][vc_column_text][/vc_column_text][/vc_tta_section][vc_tta_section title=”Specifications” tab_id=”1604679959828-9ce4c8f3-67ce940f-11e16ab7-90d9262f-f77d”][vc_column_text]
PROCESSES
| Title | Continuum™ 350 |
|---|---|
| Industries Interests | Railcar Manufacturing Heavy Equipment Manufacturing Shipbuilding |
| Output Voltage Range | 10 V – 44 V |
| Weldable Metals | Steel Stainless Steel |
| Input Voltage | 220/230/240 V 380/400 V 460/480 V 575 V |
| Rated Carbon Diameter | 1/4 in (6.4 mm) |
| Input Phase | 3-Phase |
| Input Hz | 50 / 60 Hz |
| Current Type | DC |
| Max Open Circuit Voltage | 75 VDC |
| Amperage Range | 20 A – 400 A |
| Portability | Lift Eye (Standard) Running Gear / Cart (Optional) |
| Weld Output | CC / CV |
| Net Width | 17.8 in |
| Net Height | 27.2 in |
| Net Length | 27.9 in |
| Net Weight | 127 lbs |
| Warranty | 3 Years |
CERTIFICATIONS
