APD165A DIESEL GENERATING SET 400/230 V – 50 Hz
$16,900.00
APD165A DIESEL GENERATING SET 400/230 V – 50 Hz
Discover the APD165A Diesel Generating Set, a robust and reliable power solution for commercial and industrial applications. Designed for durability and efficiency, this generator operates at 400/230 V and 50 Hz, making it suited for diverse environments such as construction sites and outdoor events. With advanced features like an efficient diesel engine and automatic voltage regulation, the APD165A ensures stable power output and exceptional fuel economy, minimizing maintenance costs and enhancing reliability. Ideal for both emergency backup and regular use, this generating set is a valuable investment for anyone needing dependable power.
Description
APD165A DIESEL GENERATING SET 400/230 V – 50 Hz
Aksa power generation system, providing optimum performance, and reliability, for stationary standby, prime power, and continuous duty applications. All generator sets are factory build, and production tested.
| Model Name | APD 165 A | ||
|---|---|---|---|
| Frequency (Hz) | 50 | ||
| Fuel Type | Diesel | ||
| Engine Made and Model | AKSA – A6CRX65TI | ||
| Alternator Made and Model | Aksa – AK 4120 | ||
| Control Panel Model | DSE 6120 | ||
| Canopy | ACP 6B |
| Voltage | STANDBY RATING (ESP) | PRIME RATING (PRP) | Standby Amper | ||
|---|---|---|---|---|---|
| kVA | kW | kVA | kW | ||
| 400/231 | 165 | 132.00 | 150 | 120.00 | 238.16 |
STANDBY RATING (ESP) : Applicable for supplying power to varying electrical load for the duration of power interruption of a reliable utility source. ESP is in accordance with ISO 8528-1. Overload is not allowed.
PRIME RATING (PRP) : Applicable for supplying power to varying electrical load for unlimited hours. PRP is in accordance with ISO 8528-1. 10 % overload capability is available for a period of 1 hour within 12-hour perod of operation.
| Engine | AKSA | ||
|---|---|---|---|
| Engine Model | A6CRX65TI | ||
| NO. OF CYLINDERS AND BUILD | 6 cylinders – in line | ||
| BORE AND STROKE | mm | 105 X 125 | |
| TOTAL DISPLACEMENT | L | 6,49 | |
| Aspiration | Turbo Charged and Intercooled(Water to Air) | ||
| COMPRESSION RATIO | 17:1 | ||
| RATED SPEED (RPM) | d/dk | 1500 | |
| OIL CAPACITY | L | 16 | |
| Standby Power (kW/HP) | 153/208.02 | ||
| Prime Power | 139/188.99 | ||
| Block Heater QTY | |||
| 1 | |||
| Block Heater Power (Watt) | 1500 | ||
| Fuel Type | |||
| Diesel | |||
| Injection Type and System | |||
| Direct | |||
| Type of Fuel Pump | |||
| PM pump | |||
| Governor System | |||
| Electronic | |||
| Operating Voltage (Vdc) | |||
| 24 Vdc | |||
| Battery and Capacity (Qty/Ah) | 2×80 | ||
| Cooling Method | |||
| Water Cooled | |||
| Cooling Fan Air Flow (m3/min) | 190 | ||
| Coolant Capacity (engine only / with radiator) (lt) | 6,35/38 | ||
| Air Filter | |||
| Dry Type | |||
| Fuel Cons. Prime With %100 Load (lt/hr) | 34.3 | ||
| Manufacturer | Aksa | |
|---|---|---|
| Alternator Made and Model | AK 4120 | |
| Frequency (Hz) | Hz | 50 |
| Power (kVA) | kVA | 150 |
| Design | 4 Pole, Brushless | |
| Voltage | V | 400 |
| Phase | 3 | |
| A.V.R. | SX460 | |
| Voltage Regulation | (+/-) | 1,5% |
| Insulation System | H | |
| Protection | IP23 | |
| Rated Power Factor | 0.8 | |
| WEIGHT COMP. GENERATOR (Kg) | 492 | |
| COOLING AIR (m³/min) | m3 | 30,84 |
| Open Type | DRY WEIGHT (kg.) (kg.) |
LENGTH (mm.) |
WIDTH (mm.) |
HEIGHT (mm.) |
TANK CAPACITY (lt.) (Lt.) |
|---|---|---|---|---|---|
| – | – | – | – | ||
| CANOPY | DRY WEIGHT (kg.) (kg.) |
LENGTH (mm.) |
WIDTH (mm.) |
HEIGHT (mm.) |
TANK CAPACITY (lt.) (Lt.) |
ACP 6B |
2070 | 3265 | 1163 | 1858 | 271 |
Radiator with mechanical fan
Protective grille for rotating and hot parts
Electric starter and charge alternator
Starting battery (with lead acid) including rack and cables
Engine coolant heater
Steel base frame and anti-vibration isolators
Spare external fuel tank (open set)
Flexible fuel connection hoses
Two bearing, class H alternator
Industrial exhaust silencer and steel bellows supplied separately
Static battery charger
Manual for application and installation
ENGINE
- Oil heater
ALTERNATOR
- Anti-Condensation Heater
- Main line circuit breaker
CONTROL SYSTEM
- Earth fault, single set
- Charge Ammeter
TRANSFER SWITCH
- Three or four pole contactor
- Three or four pole motor operated circuit breaker
OTHER ACCESSORIES
- Main Fuel Tank
- Automatic or manual fuel filling system
- Manual oil drain pump
- Low and high fuel level alarm
- Enclosure: weater protective or sound attenuated
- Trailer
- Tool kit for maintenance
