Multimatic 215 Multiprocess Welder with TIG Kit

$3,129.00

The Miller Multimatic 215 multi-process welder with TIG Kit is a 230 amp, complete portable MIG, Stick and DC TIG welding package. It comes standard with a color LCD screen and features Miller’s Auto-Set™ Elite. Auto-Set™ Elite sets MIG, Stick and TIG welding parameters automatically, all you need to do is enter metal thickness and welding wire or tungsten electrode diameter. It also allows you to fine tune weld settings manually to suit your individual preferences.

SKU: 951674 Category: Multiprocess Welding Tags: multimatic, multimatic 215

Description

Description

Miller Multimatic 215 Multiprocess Welder with Tig Kit #951674

The Miller Multimatic 215 multiprocess welder with Tig Kit is a 230 amp, complete portable MIG, Stick and DC TIG welding package. It comes standard with a color LCD screens and features Miller’s Auto-Set Elite. Auto-Set Elite sets MIG, Stick and Tig welding parameters automatically, all you need to do is enter metal thickness and welding wire or tungsten electrode diameter. It also allows you to fine tune weld settings manually to suit your individual preferences.

The Multimatic 215 runs on either 120 volt or 240 volt input power, using Miller’s exclusive multi-voltage plug (MVP) and weighs only 38 pounds. It comes complete with Miller M-100 MIG welding gun, Weldcraft 150 amp TIG torch with accessories, stick electrode holder and ground clamp.

WHAT’S INCLUDED

Multimatic® 215
Material thickness gauge #229895
6.5 ft (2 m) power cord and MVP™ adapter plugs for 120V and 240V
10 ft (3 m) MDX™-100 MIG gun
13 ft (4 m) cable electrode holder and 25 mm Dinse-style connector
10 ft (3 m) work cable and clamp
Argon and AR/CO2 mix regulator/flow gauge with hose
Spool of Hobart® .030 in (0.8 mm) solid wire
Two contact tips for .030 in (0.8 mm) wire
Quick Select™ drive roll for .024 in (0.6 mm) or .030/.035 in (0.8/0.9 mm) solid wire, and .030/.035 (0.8/0.9 mm) flux cored wire
Hook-and-loop cord wraps
TIG Kit for the Multimatic 215

Multiprocess Capabilities

MIG, flux-cored, DC stick and DC TIG processes, allowing you to build your skills.

Color LCD with Auto-Set™ Elite

Auto-Set Elite can be used on multiple materials and multiple processes with the ability to fine-tune your settings. Simple to set up and use!

Inverter Technology

Inverter technology combines best-in-class arc characteristics with the portability of a 38-pound machine. The arc is extremely forgiving to variations in arc length and travel speeds.

Two Gas Connections

There are two gas connections on the back of the machine—one for MIG and one for TIG.

Angled Drive System with Quick Select™ Drive Roll

Robust, angled wire drive with Quick Select™ drive roll. The Quick Select drive roll offers three grooves- two for different size solid wire and a third for flux-cored wire.

Multi-Voltage Plug (MVP)

Allows for connection to 120- or 240-volt receptacles without tools. Choose the plug that fits the receptacle and connect it to the power cord.

Auto Spool Gun Detect™

Auto Spool Gun Detect™ automatically detects when a MIG gun or spool gun is connected eliminating the need for a switch. The Spoolmate 100 and Spoolmate 150 are compatible with the Multimatic 215.

Smooth-Start™

Smooth-Start™ provides smooth, spatter-free MIG starts.

Fan-On-Demand™

Fan-On-Demand™ power source cooling system operates only when needed, reducing noise, energy use and the amount of contaminants pulled though the machine.

Generator Compatible

The Multimatic 215 will be able to operate and provide full output when powered by generators with 10000 Watt (10K) output or higher, such as a Miller Bobcat or Trailblazer series generator. Limited output will occur when used with smaller generators.

NOT INCLUDED

Weld leads
Shielding gas

Safety Equipment
Spool gun for aluminum welding

Specifications

PRODUCT LITERATURE

DC/12.59 Multimatic 215 – English

DC/12.59S Multimatic 215

PROCESSES

Flux Cored (FCAW)

MIG (GMAW)

Multiprocess

Stick (SMAW)

TIG DC (GTAW-DC)

GENERAL SPECIFICATIONS

Title	Multimatic® 215 Multiprocess Welder with TIG Kit
Industries Interests	DIY / Home Hobbyist Farm and Ranch Metal Art Racing / Customizing / Restoring Education / Training
Amperage	20 A – 230 A
Material Thickness	Mild Steel 24 ga. – 3/8 in. (MIG) Mild Steel 24 ga. -3/16 in. (TIG) Mild Steel 16 ga. – 3/8 in. (Stick) Aluminum 18 ga. – 3/8 in (MIG)
Weldable Metals	Aluminum Stainless Steel Steel
Input Voltage	110/115/120 V 220/230/240 V
Input Phase	1-Phase
Input Hz	50/60 Hz
Current Type	DC
Max Open Circuit Voltage	58 VDC
Wire Feed Speed	1.8 m/min – 10.8 m/min 70 IPM – 425 IPM
Portability	Handle(s) Running Gear / Cart (Optional)
Weld Output	CC / CV
Net Width	11.25 in
Net Height	12.5 in
Net Length	20.5 in
Net Weight	44 lbs
Warranty	Miller’s True Blue Warranty

Multimatic® 215
Material thickness gauge #229895
6.5 ft (2 m) power cord and MVP™ adapter plugs for 120V and 240V
10 ft (3 m) MDX™-100 MIG gun
13 ft (4 m) cable electrode holder and 25 mm Dinse-style connector
10 ft (3 m) work cable and clamp
Argon and AR/CO2 mix regulator/flow gauge with hose

Spool of Hobart® .030 in (0.8 mm) solid wire
Two contact tips for .030 in (0.8 mm) wire
Quick Select™ drive roll for .024 in (0.6 mm) or .030/.035 in (0.8/0.9 mm) solid wire, and .030/.035 (0.8/0.9 mm) flux cored wire
Hook-and-loop cord wraps
TIG Kit for the Multimatic 215
