Lincoln Electric Idealarc® 250 Stick Welder

$5,829.00

The Lincoln Idealarc 250 is a proven, industrial 250 amp AC/DC stick welder. The simple, rugged design of the Idealarc 250 allows you to set the precise heat input for your welding job. The infinite amperage dial control is unmatched for creating a highly customizable stick welding arc. Switching between AC, DC electrode positive (DCEP) and DC electrode negative (DCEN) is quick and easy, giving you the ability to work with any type of stick welding electrode.

SKU: K1053-8 Category: Tags: ,

Description

DETAILS

Lincoln Electric Idealarc 250 Stick Welder – K1053-8

The Lincoln Idealarc® 250 Stick Welder is the classic workhorse of the Lincoln Electric stick welding power source line. It produces up to 300 amps of brute AC welding strength and 250 amps of smooth DC welding performance.

  • Outstanding arc stability and built-in stabilizer – Provide popout-resistant welding with all AC electrodes.
  • Versatile welding range – With up to 300 amps AC and 250 amps DC.
  • Suitable for use with every type of electrode – Including low hydrogen, stainless steel, hardfacing, aluminum and bronze.
  • Easy set-up and operation – Full range continuous current control dial with current indicator for exact heat required for each job.
  • Change polarity – With a twist of the wrist — AC, DC+ or DC-.
  • Stackable case design – Allows machines to be stacked 3 high to save valuable floor space.
  • Fan-cooled – For extra thermal protection.

Features

  • Outstanding arc stability and built-in stabilizer
  • Versatile welding range
  • Suitable for use with every type of electrode
  • Change polarity with a twist of the wrist
  • Easy set-up and operation

Disclaimers

Warning –

Cancer and Reproductive Harm –

www.P65Warnings.ca.gov

Specifications

Product Weights & Dimensions

Dimensions (H x W x D)27 in x 19 in x 21.5 in (686 mm x 483 mm x 546 mm)
Net Weight350 lbs (158.76 kg)

Machines

Max Rating300

Basic Specification

Input Voltage230/460/575
Input Current68/34/27A AC, 86/43/34A DC
Input Hertz60
Input Phase1
Input Power230/460/575/1/60
Mode IconCC
Output Range35-300A AC, 40-250A DC
PolarityAC/DC
Rated Output250A AC/30V/30%, 250A DC/30V/30%

Application

Typical ApplicationConstruction

General Fabrication

Maintenance & Repair

Repair Welding

Warranty

Warranty3 years
