Hobart Champion 145 Welder Generator
$2,499.99
Hobart Champion 145 Welder Generator
For those who occasionally need and/or desire to weld, this stick welder/generator offers an all-in-one solution for portable power and welding, up to 4,500 watts.
Description
Hobart Champion 145 Welder Generator
Generator power
- 4,500 watts surge power and 4,000 watts continuous power.
Large muffler
- Quiet operation.
Briggs & Stratton Intek(TM) engine
- No need for you to take breaks to fill up the tank. Fuel-efficient engine with 6.25-gallon fuel tank for longer run times.
Versatile receptacle package
- With four 20A, 120 VAC GFCI receptacles and one 240 VAC (6-50R) receptacle with covers, allows you to obtain power for with 120 or 240 V tools or appliances.
145 amp DC welder
- Allows you to weld DC stick electrodes up to 5/32 in. diameter.
Lightweight and rugged
- Portable at 222 lb. (101 kg) with running gear and rollbar frame built for your added protection.
Specifications
PROCESSES
Stick (SMAW)
GENERAL SPECIFICATIONS
| Title | Champion® 145 Welder/Generator |
|---|---|
| Fuel Tank Size | 6.25 gal. |
| Fuel Type | Gasoline |
| Weldable Metals | Steel Stainless Steel Specialty Metals |
| Rated Output | 130 A @ 30% Duty Cycle |
| Single Phase Generator Continuous Power | 4000 W |
| Single Phase Generator Peak Power | 4500 W |
| Current Type | DC |
| Amperage Range | 40 – 145 |
| Weld Output | CC |
| Net Width | 20.625 in |
| Net Height | 24.75 in |
| Net Length | 31.25 in |
| Net Weight | 222 lbs |
| Warranty | 3 Years |
CERTIFICATIONS
- Running Gear
